Reed Insulation Resistance Meter R5600 1000V Dual Display with

Description

Product Overview

The Reed R5600 Insulation Resistance Meter is engineered for precise megohm measurements in industrial and scientific environments. Measuring up to 1000 V, it offers three selectable test voltages—250 V, 500 V, and 1000 V—allowing you to match the test level to the equipment under inspection. A dedicated 1 mA test current provides accurate readings in the megaohm range, while a 200 mA continuity mode quickly verifies low‑resistance paths. The meter features a large, dual‑segment LCD with backlight, ensuring readability in dimly lit spaces. Powered by four AAA batteries (included) and housed in a compact 3.5 × 8 × 2 in. case, the R5600 balances portability with durability.

Usage

Designed for electricians, HVAC technicians, and maintenance engineers, the R5600 excels in field diagnostics, equipment commissioning, and routine safety inspections. Whether you are testing motor windings, transformer insulation, or cable integrity, the meter’s selectable voltage options let you apply the appropriate stress without over‑exposing sensitive components. The built‑in continuity test is perfect for quick wire tracing and connector verification. Its rugged hard‑case protects the instrument from drops and spills, making it suitable for construction sites, factories, and laboratory settings.

Why Choose Us

Reed has a long history of producing reliable test equipment, and the R5600 continues that tradition with strict quality control and calibrated components. Each unit undergoes functional testing to meet IEC standards for insulation resistance measurement. The inclusion of a hard carrying case, test leads, an alligator clip, and a hanging strap means you receive a complete solution ready for immediate deployment. Additionally, Reed offers a one‑year limited warranty and responsive technical support to address any post‑purchase questions.

Key Features

• Three test voltages (250 V, 500 V, 1000 V) for flexible insulation testing
• 1 mA megaohm test current delivers accurate high‑resistance readings
• 200 mA continuity mode provides fast low‑resistance verification
• Large backlit dual LCD ensures clear visibility in any lighting condition
• Comes with batteries, test leads, alligator clip, hanging strap, and hard case for immediate use
• One‑year warranty and dedicated Reed technical support for peace of mind

FAQ

What is the maximum resistance the R5600 can measure?

The meter can accurately measure resistance up to 10 GΩ in the megaohm range when using the 1 mA test current.

Can I use the R5600 for low‑voltage continuity checks?

Yes, the built‑in 200 mA continuity function is designed for quick low‑resistance checks and audible beep feedback.

How long do the included AAA batteries last?

Under typical field use, the four AAA batteries provide up to 200 hours of continuous operation before replacement is needed.

Is the meter calibrated?

Each unit is calibrated at the factory to meet IEC 61010 standards and comes with a calibration certificate.

What accessories are included?

The package includes the R5600 meter, four AAA batteries, test leads, an alligator clip, a hanging strap, and a hard‑shell carrying case.
